TUBOLINEA POLES FOR FENCING

- EASY

- STANDARD

- STRONG

- EXTRA STRONG

- HARD

Available finishes:

PLASTIC COATED POLES: The sandblasted Siderlamina Sud protective treatment is ideal to remove any impurities and to guarantee a superior grip thanks to the electrostatic polyester powder coating.

HOT DIP GALVANIZED: the galvanization treatment is entrusted to third parties that ensure the qualitative requirements of the product, in compliance with UNI EN ISO 1461 rules.

TECHNICAL SPECIFICATION:

EASY

Easy Tubolinea pole
Height/cm Section AxB Weight/KG *
120 34 x 0,90 0,890
150 34 x 0,90 1,110
175 34 x 0,90 1,290
200 34 x 1,20 1,950
230 34 x 1,20 2,250
250 34 x 1,20 2,450
300 34 x 1,20 2,930

STANDARD

Standard tubolinea poles
Height/cm. Sction AxB Weight/KG *
120 38 x 0,90 1,000
150 38 x 0,90 1,130
175 38 x 0,90 1,320
200 38 x 1,20 2,460
230 38 x 1,20 2,830
250 38 x 1,20 3,075
300 38 x 1,20 3,640
350 38 x 1,20 4,300

STRONG

Strong tubolinea poles
Height/cm. Section AxB Weight/KG *
120 38 x 1,20 1,480
150 38 x 1,20 1,850
175 38 x 1,20 2,150
200 48 x 1,20 2,830
230 48 x 1,20 3,250
250 48 x 1,20 3,540
300 48 x 1,20 4,250
350 48 x 1,20 4,950

EXTRA STRONG

Extra Strong tubolinea poles
Height/cm. Section AxB Weight/KG *
120 38 x 1,50 1,620
150 38 x 1,50 2,100
175 38 x 1,50 2,400
200 48 x 1,50 3,500
230 48 x 1,50 4,000
250 48 x 1,50 4,500
300 48 x 1,50 5,250
350 48 x 1,50 6,250

HARD

Hard tubolinea poles
Height/cm. Section AxB Weight/KG *
250 60 x 2,00 7,200
300 60 x 2,00 8,640
350 60 x 2,00 10,080
400 60 x 2,00 11,520
450 60 x 2,00 12,960
500 60 x 2,00 14,400
600 60 x 2,00 17,280
650 60 x 2,00 18,720
700 60 x 2,00 20,160
600 76 x 3,00 32,460
700 76 x 3,00 37,870
* Theoretical unit weight
